Everything the ALL-IN unlocks
The same app, the same platform, and seamless Bluetooth — now controlling every door on your premises.
Flexible security levels
Dial security up or down per door — from frictionless auto-unlock all the way to required biometric verification.
Proximity unlock & lock
Doors unlock as your members approaches and lock automatically as they walk away, just like magic.
Configurable access hours
Something about different membership tiers and hours here
Magic links for guests
Send visitors a simple, secure magic link to get them through the right door — hassle free
What makes the ALL-IN reader special
Two decades of access control research distilled into one reader — now at your door.
The most configurable access system on earth
Configure granular access policies based on time, location, and membership levels
Built for every door
From glass storefronts to back-office and industrial doors, the ALL-IN secures every entrance with one consistent system.
Total visibility & control
Manage every door and credential from one portal — optimized for maximum security and convenience.
Built to fit in
Compact dimensions and flexible wiring mean the ALL-IN works with the doors, locks, and readers you already have.
Power over Ethernet
A single cable carries power and data — the cleanest install possible
Input
12W min / 65W recommended (1 Amp)
Output
12 VDC, 800 mA
Fits standard single-gang box
The reader drops into a standard single-gang low-voltage electrical box — no custom cutouts required
Box type
Standard single-gang, low-voltage
Mounting
Flush, using existing back box
Truly all-in-one
A single unit runs the door. No separate controller boards, panels, or extra readers to buy, wire, or mount.
Setup
One unit per door
Vs. competition
Lower cost, faster install
Dimensions
In-wall
Depth
1.3 in / 3.3 cm
Width
2.0 in / 5.1 cm
Height
2.9 in / 7.3 cm
Faceplate
Height
4.6 in / 11.7 cm
Width
2.8 in / 7.1 cm
Depth
0.2 in / 0.5 cm
Supports every lock
Fail-safe locks
Fail-secure locks
Parallel install with existing systems
Compatible with supplementary legacy Wiegand-based readers, so you can phase out old hardware on your own schedule.
Installation Guide
Installed at your door in minutes
The ALL-IN smart door reader fits inside a standard light-switch electrical box and runs an electromagnetic lock. If there’s a power source near the door, installation is just a matter of connecting a few wires.
Easily mounts on the inside — the secure side — of the door.
The complete installation guide
A step-by-step walkthrough for installing the ALL-IN reader — from picking the spot to wiring the lock.
STEP 01
Identify the install location
Decide exactly where the reader will live at the door. Pick a comfortable tap height with a clear line to the entry, and confirm there’s a clean cable path back to your network.
STEP 02
Run the Ethernet cable
Pull a single Cat5e/Cat6 line from your switch to the reader location. That one cable carries both data and power, so there’s no separate power run to worry about.
Tip: place the power injector as close to the reader as possible for the cleanest, most reliable power.
STEP 03
Attach lock power & Ethernet
Connect the lock power leads, then plug in the powered Ethernet cable. Once wired, the reader powers up and is ready to configure from the app.
STEP 04
Mount the hardware
Secure the reader in the wall or inside a plastic enclosure. Avoid metal enclosures — they interfere with the Bluetooth radios and cut down range.
Step 05 (Optional)
Connect a Weigand reader
Keeping existing hardware? Wire in a peripheral Weigand reader to bridge legacy credentials right alongside ALL-IN.
Need a hand with installation?
Most doors are wired in minutes — and our team is here if you have questions before, during, or after install.
